Auxiliary Gutter & Wireway Sizing Calculator

Enter conductor details to calculate the minimum gutter/wireway size per NEC requirements.

Conductor Size (AWG/kcmil)

Quantity

Notes:

16 AWG conductors are based on TFN insulated conductors.
14 AWG - 1000 kcmil conductors are based on THHN or THWN insulated conductors.
If more than 30 current-carrying conductors are present, they must be derated per NEC 310.15.
Splices and taps must be accessible and cannot take up more than 75% of the cross-sectional volume of the gutter or wireway per NEC 366.56/376.56.

DISCLAIMER:

Calculations are based on NEC 366.22 (20% fill) and 312.6(A) for bending space. Always perform due diligence and verify calculations are correct for your specific application. This calculator is not to be used in lieu of consultation with a licensed electrician, contractor, electrical engineer, or other qualified professional. Always confirm calculations and specifications with a licensed professional before implementation. We take no liability for incorrect calculations, omissions, or any damages resulting from use of this tool. Local codes and regulations may differ from NEC requirements.

Visit E-Calc Hub for more electrical calculators

Auxiliary Gutter & Wireway Sizing Calculator

Results:

4 x 4 inches

Warning: Custom Size Required
